Description
TECHNICAL PARAMETER
| Model | SUNSEE-3K | SUNSEE-5K |
|---|---|---|
| The rated power | 3000VA/2400W | 5000VA/4000W |
| INPUT | ||
| Voltage | 230 VAC | |
| Selectable Voltage Range | 90-280VAC (For Personal Computers), 170-280VAC (For Home Appliances) | |
| Frequnecy Range | 50Hz/60Hz (Auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt. Model) | 230VAC ± 5% | |
| Surge Power | 6000VA | 10000VA |
| Power factor | 0.8 | |
| Efficiency(Peak) | > 90% | |
| Transfer Time | 10ms (For Personal Computers), 20ms (For Home Appliances) | |
| Wave form | Pure sine wave | |
| No load current | 1.36A | 1.15A |
| BATTERY | ||
| Battery voltage | 24VDC | 48VDC |
| Low battery alarming voltage | 22.5VDC | 43.5VDC |
| Low battery cut off protection voltage | 20.5Vdc | 41.00VDC |
| Low battery recovery voltage | 23.5VDC | 45.5VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| Overcharge Protection | 32VDC | 62VDC |
| MPPT SOLAR CHARGER & AC CHARGER | ||
| Maximum PV Array Power | 1800W | 4800W |
| MPPT Range Operation Vol | 18-145VDC | 36-115VDC |
| Maximum PV Array Open Circuit Vol. | 145VDC | 145VDC |
| Standby Power Consumption | 2W | 2W |
| Maxmum Solar Charge Current | 60A | 80A |
| Maxmum AC Charge Current | 60A | 60A |
| Maxmum Charge Current | 120A | 120A |
| Maxmum Efficiency | 98% | |
| BEST PANEL CONFIGUTATION | ||
| Max. generated from solar charger | 60Amp, 1800W | 80Amp, 4800W |
| Best Panel configuration | 250Wp*6pcs(1500wp) | 250Wp*18pcs (4500Wp) |
| PHYSICAL | ||
| Products Dimension, D*W*H(mm) | 465*300*116 | 470.5*300*136 |
| Packing size, D*W*H(mm) | 543*394*205 | 549*394*224 |
| Net Weight (kgs) | N.W.: 8.4, G.W.: 10.1KGS | N.W.: 10.81, G.W.: 12.86KGS |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Operation Temperature | 0℃-50℃ | |
