Description
The 8kw hybrid solar inverter has a dual 18A MPPT tracker and an input power of up to 8,000W to provide you with plenty of power. With Touchable LCD and status LED ring with RGB lights. It supports user programmable multiple operation .It supports battery-less work and parallel-able up to 6pcs. Smart BMS built inside help compatible with lithium battery.
SUNPOLO 8.2KW On/Off Grid Solar inverter
8KW Real Hybrid solar inverterwith 120AMPPThigh PV input and RGB light, various communication as USB/RS232/Dry Contact
Three lighting effects:
Cycling
Wheel
Chasing
#col-183965079 > .col-inner {
padding: 10% 10% 10% 10%;
max-width: 520px;
}
Bigger Size LCD Display
1. MFD (multi-function display) setting2. AC+Solar charging biggest current 50A3. Display PV information
#col-690747005 > .col-inner {
padding: 10% 10% 10% 10%;
max-width: 520px;
}
#section_1819789340 .section-bg-overlay {
background-color: rgba(255, 255, 255, 0.85);
}
Application Scenarios for 8kw Solar Inverters
The 8kw hybrid solar inverter is suitable for off-grid solar systems for homes and government.
Parameters of the SUNPOLO 8KW Hybrid Solar Inverter
| Model No. | SUNPOLO 8.2KVA |
|---|---|
| Basical information | |
| Max. PV Input Power | 8000W |
| Rated AC Output Power | 8000W |
| Grid-Tie Operation | |
| PV Input (DC) | |
| Nominal DC Volt/Max DC Voltage | 360VDC/450VDC |
| Start-up Voltage/Initial Feeding Voltage | 120VDC |
| MPPT Voltage Range | 120-450VDC |
| No. of MPPT Tracker/Max. Input Current | 2PCS*18A MPPT Tracker (4000W*2) |
| AC Input (AC) | |
| AC Start-up Voltage/Auto Restart Volt. | 120Vac-140Vac/180Vac |
| Acceptable Input Voltage Range | 90-280Vac or 170-280Vac |
| Max. AC Input Current | 63A |
| Grid Output in Grid-Tie/Hybrid Operation (AC) | |
| Nominal Output Volt | 220Vac/230Vac/240Vac, Single Phase |
| Output Voltage Range | 184V-265Vac or 195-253V (Selectable) |
| Nominal Output Current | 34.8A |
| Power Factor | 1 |
| Max. Conversion Efficiency (DC/AC) | 96% |
| Battery Mode Output (AC) | |
| Nominal Output Volt | 220Vac/230Vac/240Vac |
| Waveform | Pure sine wave |
| Efficiency(DC to AC) | 93% |
| Battery & Charger | |
| Battery Type Supported | Lead Acid/VRLA/AGM/Deep Cycle/Gel/Flooded/Tubular/Lithium-Ion |
| Nominal Battery Voltage | 48Vdc |
| Max Solar Charge Current | 120A |
| Max AC Charge Current | 120A |
| Max Total Charge Current | 120A |
| General | |
| Physical | |
| Products Dimension,D X W X H (mm) | 552*422*152 |
| Product Net Weight(kgs) | 18.4 |
| Product Gross Weight(kgs) | 20.5 |
| Packing Dimension,D X W X H (mm) | 700mm*510*mm*232mm,1PC/CTN |
| Parallel functions Optional | Yes, optional, MAX. 6pcs |
| Communication Interface | RS232,USB,WIFI,TOUCH LCD |
| Environment | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | -10℃ to 50℃ |
| Storage Temperature | -15℃ to 60℃ |
| *Product specifications are subject to change without further notice | |
