Description
TECHNICAL PARAMETER
| MODEL | SUNON IV 4.2K/24V | SUNON IV 6.2K/48V |
|---|---|---|
| Rated Power | 4200VA/4000W | 6200VA/6000W |
| BATTERY | ||
| Battery Voltage | 24 VDC | 48 VDC |
| Floating Charge Voltage | 31.5 VDC | 61 VDC |
| Overcharge Protection | 33 VDC | 63 VDC |
| INPUT | ||
| Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% | |
| Surge Power | 8400VA | 12400VA |
| Efficiency (Peak) | 90% ~ 93% | |
| Transfer Time | 15 ms (For Personal Computers) ; 20 ms (For Home Appliances) | |
| Waveform | Pure sine wave | |
| SOLAR CHARGER & AC CHARGER | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Power | 5000W | 6000W |
| MPPT Range @ Operating Voltage | 60 ~ 450 VDC | |
| Maximum PV Array Open Circuit Voltage | 500 VDC | |
| Maxmum Solar Charge Current | 120 A | 120 A |
| Maximum AC Charge Current | 100 A | 100 A |
| Maximum Charge Current | 120 A | 120 A |
| PHYSICAL | ||
| Dimension, D x W x H (mm) | 481 x 300 x 130 | |
| Net Weight (kgs) | 13.0 | 13.0 |
| Communication Interface | USB/RS232/RS485(BMS)/Local WiFi/Dry-contact | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Operating Temperature | -10°C to 50°C | |
| Storage Temperature | -15°C to 60°C | |
