Description
SAKO Lithium Battery Pack With 24V60Ah
| Model No. | ESS-1KW |
|---|---|
| Basic information | |
| Max. PV Input Power | 1200W |
| Rated AC Output Power | 1000W |
| Output peak power (W) | 2000W(200ms) |
| Grid-Tie Operation | |
| Rated power | 720W |
| Grid connected power | 600W MAX |
| Mains charging current | 0-40A adjustable |
| AC input voltage range | 90-265VAC |
| Input frequency range | 50HZ/60HZ ±3HZ |
| THDI | 3% |
| Rectification efficiency | 91.2% Max. |
| AC input connection type | L/N/PE |
| Solar controller parameters | |
| Controller type | MPPT controller |
| Rated battery voltage | 25.6V |
| Charging current | 30A max |
| PV input voltage range | 36-100VDC |
| PV input power | 1200W max. |
| PV charging power | 800W max. |
| Conversion efficiency | 96%max |
| Number of PV input channels | 1 |
| PV input interface | Anderson interface |
| Output (AC) | |
| Nominal Output Volt | 220Vac, Single Phase |
| output frequency | 50/60hz |
| Output waveform | Pure sine wave |
| Nominal Output Current | 4.5A |
| Power Factor | 1 |
| Efficiency | |
| Max. Conversion Efficiency (DC/AC) | 91.5%max |
| Energy storage information | |
| Nominal battery voltage | 25.2VDC |
| Core material | Lithium iron phosphate battery |
| Energy storage capacity | 1536wh |
| Core cycle | ≥2000cycles&25℃ Standard charging and discharging process@80%SOH |
| Spare parts information | |
| PV cable | One 5m double core 4m² PV cable |
| Power cord | 1 European power cord 1.8m |
| General | |
| Physical | |
| Products Dimension, D X W X H (mm) | 790*395*160mm |
| Product Net Weight(kgs) | 30kg |
| Environment | |
| The noise | 60dB Max（1 meter） |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | -10℃ to 50℃ |
| Storage Temperature | -15℃ to 60℃ |
| Altitude | Below 1,500 meters above sea level. When the altitude is higher than 1500 m , derating is required. |
| *Product specifications are subject to change without further notice | |
